Weight controller
flexcw
Reliability and robustness for the dynamic weight control of all kinds of products transported by conveyor belt in any type of package and presentation.
- Important economies to product saving and waste reduction
- Available solutions for a wide range of weighing
- Suitable to work under HACCP and ISO 22000 regulations
- Great precision
- Total sanitary design
Fact Sheet
SPECIFICATIONS
| MODELS | LIGHTWEIGHTCW 450L - CW 600L | MEDIUMCW 700M -CW 900M | HEAVYCW 900P - CW 1200P |
|---|---|---|---|
| Weighing range (Kgs) | 0 to 4 kgs | 4 to 10 kgs | 10 to 50 kgs |
| Accuracy (grs)* | +/- 2 to 5grs (*) | +/- 5 to 10 grs (*) | +/- 10 to 50 grs (*) |
| Max Production (Unit/Min) | 90/60 | 60/40 | 40/30 |
| Width “L” (mm) | 190-240-290-390 | 400-600 | 400-600 |
| Lengths “A” (mm) | 450-600 | 700-900 | 900-1200 |
| Screen Height (mm) | 1300 | 1300 | 1300 |
| Working temperature (Cº) | 0º to 50º C |
| IP Protection | IP-54 (optional IP-65) |
| Termination | Blasted Stainless steel AISI 304 |
| Supply voltage | 3x380V / 50 Hz |
| Required air pressure | 4kg/cm2 |
| Conveyor belt | continuous - sanitary - white |
| Display and command | 8" TACTILE Display (color) |
(*) Final operational accuracy will depend on product weight and production speed.
